huawei server E6000 GE & FC switching modules

The E6000 supports gigabit Ethernet (GE) switching modules, fabric channel (FC) switching modules, and straight-through modules. GE and FC switching modules connect to the server blades and management modules (MMs) through the backplane for exchanging data packets, and control and management packets. This provides high-speed data transmission. Straight-through modules connect to the server blades through the backplane for providing external network ports for the server blades.

Switching modules provides three switching planes A, B, and C that are independent of each other. The three switching planes are described as follows:
* Plane A consists of the switching modules installed in slots A1 and A2.
* Plane B consists of the switching modules installed in slots B1 and B2.
* Plane C consists of the switching modules installed in slots C1 and C2.

Switching plane A (slots A1 and A2) supports GE switching modules. Switching planes B (slots B1 and B2) and C (C1 and C2) are high-speed switching planes that support 10 GE, 4.25 G FC, and 20 G InfiniBand switching modules and are backward compatible with GE or FC switching modules. Figure 1 shows the slot numbers of switching modules. Each switching module slot connects to the 10 slots of server blades.

1）Gigabit Ethernet (GE) switching modules

2) Fabric channel (FC) switching modules

Hong Telecom Equipment Service LTD have more switching modules for your option:

03030LQA BC0D00GPTA00 : NX910 GE Through Board
03030MXK BC0D00EFGF00 : NX112 L3 GE switch module (4 * GE electrical interface + 2 * 10GE uplink interface, stackable)
03030MXJ BC0D00EFGF10 : NX113 L3 GE switch module (4 * GE optical port + 2 * 10GE uplink port, stackable)
03021LTG BC0MFCPBE600 : 8G FC optical port through board
03021XFU BC01TGBA : 10GE optical interface
03030AYG BC0D00FCBA00 : NX120 FC switching module
05330488 BC0LICENSE00 : FC Switch Cascade Feature License - for 98050172
98080466 BC1FCBC00 : NX220-Full with 6 optical modules-HU-5430-0001-M- Includes 3-year maintenance
05330493 BC0LICENSE01 : FC-Fabric-Full Fabric License
05330492 BC0LICENSE02 : FC Switching-Procro-ISL Trunking License
03055030 BC0D00TGXA01 : NX230 8 * 10GE switch board (including four 850nm multi-mode optical modules)
